HORIZONTAL GRINDING MACHINES

Profile Horizontal Grinding Machines RTM series

The horizontal axis grinders belonging to the RTM series are mainly designed for precise grinding operations on medium-big size items, such as: columns, cariage, moulds, guides, straight blades, etc. The different experiences had with the design of special grinders have positively influenced choices and solutions that today allow standard grinders to face international competition and more and more exacting customers' requirements, with the awareness that product quality and reliability are the main competitive factors.

RTM series grinding performances

		RTM 100-150.50CN	RTM 160-200-300-400.75CN
length ground	mm	1000 - 1500	1600-2000-3000-4000
width ground	mm	500 (550)	750 (850)
working surface	mm	1000x450 1500x450	1600x750 2000x750 3000x750 4000x750
standard grinding height	mm	500	500-700
grinding wheel dimensions	mm	400x50x127	500x100x203
table traverse speed	m/1'	1 - 35	1 - 35
automatic increment	mm	0.001	0.001
main motor	kW	7.5	15
net weight	Kg	5000-6000	9500-10500-12500-15000
